Python-UNO bridge

IMPORTANT: Workarounds for pyuno problems in OOo3.0.0

1. (windows only) The python scripting framework (scripts within openoffice via Extras/Macro/) does not work, when you have a python 2.3 installed on your windows system (more precisly, when there exists a python23.dll in your windows/system32 directory). You can work around it for now by copying Basis\program\python23.dll to program\. beside the soffice.bin executable. This forces the soffice process to load the correct library beside the office process. (94993)
2. (windows only) When you try to connect to a running office process, you get

    __main__.com.sun.star.connection.NoConnectException: Connector  couldn't connect to socket (WSANOTINITIALISED, WSAStartup() has not been called)

   You can workaround this, by placing a

   import socket

   in the top of your script (95028)
3. (windows only) The python program crashes or you get an attribute error

   AttributeError: getCurrentComponent  (or some other attribute)


   This is because the types could not be loaded due to changes in the uno bootstrapping mechanism. You can work around it for now by setting the URE_BOOTSTRAP variable (adapt to your installation path, replace every space with a %20, change \ to /).

   set URE_BOOTSTRAP=file:///C:/Program%20Files/OpenOffice.org%203/program/fundamental.ini

   and run python. Alternatively, you can set URE_BOOTSTRAP=fundamental.ini when your current working directory is beside the python executable. (95024)
4. (windows only) Interactive mode in python does not work correctly When you start the python executable without parameters, the interactive session runs somewhat fuzzy (at least on my machine). When you get the prompt >>>> , everything you type will be interpreted as a shell command. When you then just press return, you are prompted with your current working directory, here you can place a python command, so in short, you have to press return 2 times after every python command (95037).
5. ( unix only), you need to set LD_LIBRARY_PATH correctly before starting the python executable, eg.

   export set LD_LIBRARY_PATH=$LD_LIBRARY_PATH:../../openoffice.org/ure/lib:../../openoffice.org/basis3.0/program ./python

Contents

Translations

Find here a shortened Spanish version of this document.

Introduction

The Python-UNO bridge allows to

• use the standard OpenOffice.org API from the well known python scripting language.
• to develop UNO components in python, thus python UNO components may be run within the OpenOffice.org process and can be called from Java, C++ or the built in StarBasic scripting language.
• create and invoke scripts with the office scripting framework (OOo 2.0 and later).

You can find the most current version of this document from http://udk.openoffice.org/python/python-bridge.html

Download

You can also download this documentation for offline work.

Download pyuno-doc.zip ( less than 0.5 MB).

State

The Python-UNO bridge is feature complete, but has not been used extensively, so it may contain some bugs. It is now integrated in the OpenOffice.org source trees. (OpenOffice.org 1.0.x is not supported.)

The documentation in its current state is targeted at developers who have already some experience with OpenOffice.org API and with some other programming language (Java/C++/StarBasic). It is recommended that you read that some background information from the developer manual before looking at the specifics of python.

PyUNO tutorial for OpenOffice.org

PyUNO Installation

PyUNO bridge modes

PyUNO can be used in three different modes:

1. Inside the OpenOffice.org process within the scripting framework (OOo 2.0 and later only !!),
2. Inside the python executable (and outside the OOo process)

   Use this mode, when you

   • begin to use PyUNO (as it is the more intuitive approach).
   • want to trigger script execution by starting a separate process (e.g. a cgi-script within a http-server).
   • want the shortest turnaround times (code - execute - code - execute ...)

   Hello World

   Make sure, that OpenOffice.org is not running (note that on windows you must also terminate the quick starter in the system tray at the right bottom of your desktop). Start a system shell ( cmd on Win NT/2000/XP, command on Win9x, tcsh or bash on Unix). Switch to the Office program directory (e.g. C:\Program Files\OpenOffice.org1.1\program ) and start the office with the following command line parameters

   c:\Program Files\OpenOffice1.1\program> soffice "-accept=socket,host=localhost,port=2002;urp;"

   Now use your favourite text editor to create the following hello_world.py sample program:

   import socket # only needed on win32-OOo3.0.0 import uno # get the uno component context from the PyUNO runtime localContext = uno.getComponentContext() # create the UnoUrlResolver resolver = localContext.ServiceManager.createInstanceWithContext( "com.sun.star.bridge.UnoUrlResolver", localContext ) # connect to the running office ctx = resolver.resolve( "uno:socket,host=localhost,port=2002;urp;StarOffice.ComponentContext" ) smgr = ctx.ServiceManager # get the central desktop object desktop = smgr.createInstanceWithContext( "com.sun.star.frame.Desktop",ctx) # access the current writer document model = desktop.getCurrentComponent() # access the document's text property text = model.Text # create a cursor cursor = text.createTextCursor() # insert the text into the document text.insertString( cursor, "Hello World", 0 ) # Do a nasty thing before exiting the python process. In case the # last call is a oneway call (e.g. see idl-spec of insertString), # it must be forced out of the remote-bridge caches before python # exits the process. Otherwise, the oneway call may or may not reach # the target object. # I do this here by calling a cheap synchronous call (getPropertyValue). ctx.ServiceManager

   Now start the above script with the python script located in the program directory

   c:\Program Files\OpenOffice1.1\program> .\python hello_world.py

   Note: You must use the script/batch file in the program directory to start python, simply starting the python executable in the runtime directory (or from python installation installed somewhere else on your machine) will not work.


   This scripts prints "Hello World" into the current writer document.

3. Inside the OpenOffice.org (OOo) process



   Use this mode, when

   • you want to easily roll out your code to multiple other machines (using UNO packages)
   • your scripts shall get triggered by UI events (menu or toolbars)
   • you have collected some experience with PyUNO
   • you want your script to run with the best performance

   Hello World

   The above Hello World example is now recoded as a python UNO component, which means, that the code that does the insertion needs to be embedded in a python class. Additionally, the connecting-to-the-office-code needs to be replaced by a distinct entry point, which is used by the python loader to instantiate the python class.

   hello_world_comp.py:

   import uno import unohelper from com.sun.star.task import XJobExecutor # implement a UNO component by deriving from the standard unohelper.Base class # and from the interface(s) you want to implement. class HelloWorldJob( unohelper.Base, XJobExecutor ): def __init__( self, ctx ): # store the component context for later use self.ctx = ctx def trigger( self, args ): # note: args[0] == "HelloWorld", see below config settings # retrieve the desktop object desktop = self.ctx.ServiceManager.createInstanceWithContext( "com.sun.star.frame.Desktop", self.ctx ) # get current document model model = desktop.getCurrentComponent() # access the document's text property text = model.Text # create a cursor cursor = text.createTextCursor() # insert the text into the document text.insertString( cursor, "Hello World", 0 ) # pythonloader looks for a static g_ImplementationHelper variable g_ImplementationHelper = unohelper.ImplementationHelper() # g_ImplementationHelper.addImplementation( \ HelloWorldJob, # UNO object class "org.openoffice.comp.pyuno.demo.HelloWorld", # implementation name # Change this name for your own # script ("com.sun.star.task.Job",),) # list of implemented services # (the only service)

   The code needs to be linked to a user event. This can be done e.g. with the following configuration settings :

   Addons.xcu:

   <?xml version="1.0" encoding="UTF-8"?> <oor:node xmlns:oor="http://openoffice.org/2001/registry" xmlns:xs="http://www.w3.org/2001/XMLSchema" oor:name="Addons" oor:package="org.openoffice.Office"> <node oor:name="AddonUI"> <node oor:name="AddonMenu"> <node oor:name="org.openoffice.comp.pyuno.demo.HelloWorld" oor:op="replace"> <prop oor:name="URL" oor:type="xs:string"> <value>service:org.openoffice.comp.pyuno.demo.HelloWorld?insert</value> </prop> <prop oor:name="ImageIdentifier" oor:type="xs:string"> <value>private:image/3216</value> </prop> <prop oor:name="Title" oor:type="xs:string"> <value xml:lang="en-US">Insert Hello World</value> </prop> </node> </node> </node> </oor:node>

   Both files must be packaged up into a single zip file by using your favourite zip utility, e.g. infozip.

   zip hello_world.zip Addons.xcu hello_world_comp.py adding: Addons.xcu (deflated 55%) adding: hello_world_comp.py (deflated 55%)

   This package can then be deployed into an OpenOffice.org installation using the pkgchk tool, which is located in the OOo program directory. Note, that the office must have been stopped before installing the package.

   Note: Make sure, that the PYTHONPATH environment variable is NOT set when you start pkgchk or soffice (see #i17339#). This may require, that you create a batch file for soffice on windows, unset PYTHONPATH in the system configuration or always start soffice from the shell with set PYTHONPATH= (windows) or unsetenv PYTHONPATH (Unix tcsh shell).

   c:\Program Files\OpenOffice.org1.1\program> pkgchk hello_world.zip c:\Program Files\OpenOffice.org1.1\program>

   On success no output is given by the tool. When OpenOffice.org starts there is a new menu entry (see Tools/Additional Components/Insert Hello World).

Examples

• ooextract.py
  A command line tool, that extracts the text, html or pdf content from a StarWriter document and writes it to a different file or (optionally) prints it to stdout (grep your office documents).

• oomerge.py
  A command line tool, that creates a new document by appending multiple single documents

• swriter.py
  A command line program, that fills a writer document with some text and tables.

• swritercomp.py, swritercompclient.py
  Same as above, but implemented as a python UNO component, so that it runs within the office process. This shows the performance benefit of having scripts run within one process.

  You must add the swritercomp.py program with the pkgchk tool (see below) to the office installation and can then use the swritercomp_client.py program to execute it.

• biblioaccess.py
  A command line program, that displays the contents of the biblio sample database that comes with OpenOffice.org.

• python-tokencounter-calc-addin.oxt
  Adds a function named

  tokencount

  to calc, which counts the number of words within a calc cell. After adding the extension, the office must be restarted (including terminating the quickstarter) to make the function appear in the function list.
• Your example (Please send more examples, so that they can be added here).

UNO Language binding

UNO Type mapping

#idl signature void takeBool( [in] boolean bool )

unoObject.takeBool( 1 )       # valid, passing true (PyUNO runtime
                              # does the conversion
unoObject.takeBool( True) )   # valid, passing true
unoObject.takeBool( False )   # valid, passing false

# idl signature void foo( [in] any value )

# implementation expects a boolean (which is separately documented
# e.g. in the service specification.
unoObject.foo( True ) # valid, pass a true
unoObject.foo( 1 )    # bad, just passing a 1, implementation will
                      # probably not be able to deal with it correctly.

# idl signature foo( [in] string value )
# both lines are valid
unoObject.foo( u'my foo string' )
unoObject.foo( 'my foo string' )

# idl signature foo( [in] char c)
unoObject.foo( uno.Char( u'h' ) )  #valid
unoObject.foo( 'h' )               #wrong

from com.sun.star.beans import PropertyValue
from com.sun.star.uno import Exception,RuntimeException

propVal = PropertyValue()                 # Default constructor
propVal.Name = "foo"
propVal.Value = 2

if propVal == PropertyValue( "foo", 2 ):  # Memberwise constructor
   # true !
   pass

if propVal == PropertyValue( propVal ):   # Copy Constructor
   # true

struct = uno.createUnoStruct( "com.sun.star.beans.PropertyValue" )

struct.Name = "foo"
struct2 = struct
struct2.Name = "python"           # modifies also struct, probably not desired !
unoObject.call( struct, struct2 ) # passes the same struct 2 times !

struct.Name = "doobidooo"         # even worse style. If the UNO object is implemented
                                  # in python, you possibly modify the callee's value.
				  # Don't do this !

# idl signature XInterface createInstanceWithArguments(
#                        [in] string servicename,  [in] sequence <any> )
doc = smgr.createInstanceWithArguments( "foo.service", ("arg1",2))

# idl signature writeBytes( [in] sequence%lt; byte > data )
#
out.writeBytes( uno.ByteSequence( "abc" ) )

# you could also write the following
begin = uno.ByteSequence( "ab" )
out.writeBytes( begin + "c" )

# but this does not work !
out.writeBytes( "abc" ) # ERROR, no implicit conversion supported by the runtime !


# idl signature long readBytes( [out] sequence<byte> , [in] length )
len,seq = in.readBytes( dummy, 3 )

# the statements do the same thing
print seq == "abc":
print seq == uno.ByteSequence( "abc" )

from com.sun.star.beans.PropertyConcept import ATTRIBUTES
.
.
.
# the following 3 lines are equivalent
unoObject.setConcept( ATTRIBUTES )
unoObject.setConcept( 4 )
unoObject.setConcept( uno.getConstantByName( "com.sun.star.beans.PropertyConcept.ATTRIBUTES" ) )

# constructs a uno.Any, that contains a byte
byteAny = uno.Any( "byte" , 5 )

# constructs a sequences of shorts
byteAny = uno.Any( "[]short", (4,5))

# the normal call
uno.setPropertyValue( "foo", (4,5))

# the uno.invoke call
uno.invoke( obj, "setPropertyValue" , ("foo",uno.Any( "[]short", (4,5))) )

import uno
ctx = uno.getComponentContext()
class MagicTransformer:
    def __init__( self , ctx ):
        self.inv = ctx.ServiceManager.createInstanceWithContext(
            "com.sun.star.script.Invocation", ctx )
        self.insp =  ctx.ServiceManager.createInstanceWithContext(
            "com.sun.star.beans.Introspection", ctx )
    def transform( self, struct , propName, value ):
        myinv = self.inv.createInstanceWithArguments( (struct,) )
        access = self.insp.inspect( myinv )
        method = access.getMethod( "setValue" , -1 )
        uno.invoke( method, "invoke", ( myinv, ( propName , value ) ))
        method = access.getMethod( "getMaterial" , -1 )
        ret,dummy = method.invoke(myinv,() )
        return ret

transformer = MagicTransformer( ctx )

# by default, the 100 becomes a byte
special = PropertyValue("TabStopPosition",0,100,DIRECT_VALUE)
print "before" + str(special)

# however, we want the 100 to be a int32 (which is a long in UNO idl)
special = transformer.transform( special, "Value" , uno.Any( "long", 100 ) )
print "after" + str(special)

Implementing UNO objects

To be an UNO object, a python class MUST implement the com.sun.star.lang.XTypeProvider interface by implementing two methods getTypes() and getImplementationId(), which inform the python-UNO bridge, which concrete UNO interfaces the python class implements. The getTypes() function defines, which interfaces are implemented by the class.

To make this easier, there exists a unohelper.Base class, where a python UNO object should derive from. You can then implement a UNO interface simply by deriving from the wanted interfaces. The following example implements a com.sun.star.io.XOutputStream, which stores all data written into the stream within a ByteSequence. (Note that this is quite a poor implementation, which is just for demonstration purposes).

import unohelper
from com.sun.star.io import XOutputStream
class SequenceOutputStream( unohelper.Base, XOutputStream ):
      def __init__( self ):
          self.s = uno.ByteSequence("")
          self.closed = 0

      def closeOutput(self):
          self.closed = 1

      def writeBytes( self, seq ):
          self.s = self.s + seq

      def flush( self ):
          pass

      def getSequence( self ):
          return self.s

Implementing Python UNO components

There exists a loader for python components. It allows to create instances of python classes not just within the python process but in every arbitrary UNO process including OpenOffice.org. The python loader loads the python runtime on demand if it is not already loaded and executes python code within the root python interpreter.

If the reader is unfamiliar with the component registration process, it should visit the OpenOffice.org developer manual for a comprehensive explanation.

The python loader currently supports the following protocols for incoming urls :

After the module has been imported, the python loader looks for a module-global variable with the name g_ImplementationHelper, which is expected to be an instance of unohelper.ImplementationHelper. The following sample code makes a uno component out of the above UNO object ( note that the component is not useful, because there is no UNO method to retrieve the tuple nor does a com.sun.star.io.OutputStream service specification exist, it's just here as an example).

import unohelper
from com.sun.star.io import XOutputStream

g_ImplementationHelper = unohelper.ImplementationHelper()

class TupleOutputStream( unohelper.Base, XOutputStream ):
      # The component must have a ctor with the component context as argument.
      def __init__( self, ctx ):
	  self.t = ()
	  self.closed = 0

      # idl void closeOutput();
      def closeOutput(self):
	  self.closed = 1

      # idl void writeBytes( [in] sequence<byte>seq );
      def writeBytes( self, seq ):
	  self.t = self.t + seq      # simply add the incoming tuple to the member

      # idl void flush();
      def flush( self ):
	  pass

      # convenience function to retrieve the tuple later (no UNO function, may
      # only be called from python )
      def getTuple( self ):
	  return self.t

# add the TupleOutputStream class to the implementation container,
# which the loader uses to register/instantiate the component.
g_ImplementationHelper.addImplementation( \
	TupleOutputStream,"org.openoffice.pyuno.PythonOutputStream",
	                    ("com.sun.star.io.OutputStream",),)

regcomp -register -br types.rdb -br services.rdb -r services.rdb -c vnd.openoffice.pymodule:tuplestrm

You can of course also use the pkgchk tool as explained in the tutorial chapter with

pkgchk tuplestrm.py

, but note, that this command creates a copy of the file (when the script changes,it must be redeployed using the above command).

The component can be instantiated e.g. from OpenOffice.org Basic with

tupleStrm = createUnoService( "com.sun.star.io.OutputStream" )
tupleStrm.flush()

Out parameter handling

UNO out parameters are handled through the python multiple return value feature. For pure outparameters, a dummy None value should be used as a place holder. This is best explained with an example. Lets' assume we have the following IDL method spec

long foo( [in] long first, [inout] long second, [out] third )

A python UNO object implements such a method the following way:

class Dummy( XFoo ):
    def foo( self, first,second,third):
        # Note: the value of third is always None, but it must be there
	#       as a placeholder if more args would follow !
        return first,2*second,second + first

ret,second,third = unoObject.foo( 2, 5 , None )
print ret,second,third    # results into 2,10,7

This also emphasizes, that out-parameters are quite close to multiple return values (though the semantic association of a inout parameter gets lost).

However, note that

• you must have the correct number of return values either in the calling and implementing code, otherwise you will get a RuntimeException during the call.
• a void method always returns a None followed by possible out parameters, so when you have a void method with one out parameter you must assign the output to two variables (though the first one will always be None).
• a python object implementing a void method with out parameters MUST always return None as the first parameter.

Exception handling

Example for catching

from com.sun.star.uno  import RuntimeException
from com.sun.star.lang import IllegalArgumentException
from com.sun.star.connection import NoConnectException
try:
    uuresoler.resolve( "uno:socket,host=localhost,port=2002;urp;StarOffice.ComponentContext" )
except NoConnectException e:
    print "The OpenOffice.org process is not started or does not listen on the resource ("+e.Message+")"
except IllegalArgumentException e:
    print "The url is invalid ( "+ e.Message+ ")"
except RuntimeException e:
    print "An unknown error occurred: " + e.Message

Example for throwing

from com.sun.star.io import IOException
class TupleOutputStream(XOutputStream,unohelper.Base):
      def writeBytes( self, seq ):
          if self.closed:
	     raise IOException( "Output stream already closed", self )
          self.t = self.t + seq

current context support

pyuno supports the uno current context concept. There exist the functions uno.getCurrentContext() und uno.setCurrentContext( newContext ).

Furthermore, there exists a class unohelper.CurrentContext. The constructor accepts a hashmap with name/value pairs and the former context for delegation. Usage pattern:

   oldContext = uno.getCurrentContext()
   try:
      uno.setCurrentContext(
          unohelper.CurrentContext( oldContext,{"My42":42}) )

      # ... do some uno calls, which may interpret the "My42"
   finally:
      uno.setCurrentContext( oldContext )

unohelper module

The unohelper.py module contains some extra functions/classes, which are nice to use with pyuno, but not mandatory. This paragraph lists some of the unohelper.py features.

Logging

The pyuno bridge can now log every call bridged between python and uno. This may be a useful help when you need to debug or profile your code. There are two environment variables, which activate logging:

(Since OOo 2.4) Implementing UNO components with multiple source files

This now means that python uno components can be implemented with an arbirtrary number of python source files which can be deployed/undeployed via the uno package mechanism. It also means, that you can now use the unohelper.Base implementation even if you have defined your own interface types (by lazy loading the new types so that they don't get used during registration process).

import uno
import unohelper

def createInstance( ctx ):
    # pythonpath/org/openoffice/comp/addin/sample/python/tokencounter.py contains the component implementation
    # TokenCounter uses a new type, importing it at the top of this file
    # leads to a failure during adding the extension to OOo. createInstance does not get called
    # during registration
    import org.openoffice.comp.addin.sample.python.tokencounter
    return org.openoffice.comp.addin.sample.python.tokencounter.TokenCounter( ctx )

# pythonloader looks for a static g_ImplementationHelper variable
g_ImplementationHelper = unohelper.ImplementationHelper()
g_ImplementationHelper.addImplementation( \
	createInstance,"org.openoffice.comp.addin.sample.python.TokenCounter",
        ("com.sun.star.sheet.AddIn",),)

Have a look at the sample calc addin to see how it works.

Note that there are some negative side effects:

• code added through this mechanism can only be changed with a restart of the office process (as it got added to sys.modules). This is especially limitation for script developers.
• two independend uno packages from different developers may interfere each other, when they have name clashes in their code (e.g. same 3rd party product, but different versions).
• if such a situation occurs, in general the last used component will not work properly (which one is the last used component may also depend on the path of user interactions in the office process)

Dependencies

This chapter is most interesting for people who want to use the Python-UNO bridge independently from OpenOffice.org.

Unlike the Java or C++ UNO binding, the python UNO binding is not self contained. It requires the C++ UNO binding and additional scripting components. These additional components currently live in the shared libraries typeconverter.uno, invocation.uno, corereflection.uno, introspection.uno, invocadapt.uno, proxyfac.uno, pythonloader.uno (on windows typeconverter.uno.dll,...; unix typeconverter.uno.so,...).

Often, the components for setting up an interprocess connection are also required. These are uuresolver.uno, connector.uno, remotebridge.uno, bridgefac.uno shared libraries.

The path environment variables ( LD_LIBRARY_PATH on Unix, PATH on Windows) must point to a directory, where the core UNO libraries, the above listed components and the pyuno shared library is located. (On Unix, there exists two files: libpyuno.so containing the code and a pyuno.so which is needed for importing a native python module). Additionally, the python module uno.py, unohelper.py and pythonloader.py must be located in a directory, which is listed in the PYTHONPATH environment variable.

Bootstrapping pyuno from the python executable

When the uno module gets first imported from an arbitrary python script, it must bootstrap a properly prepared UNO component context.

# bootstraps the uno component context
import uno

# retrieve the already bootstrapped component context
unoContext = uno.getComponentContext()

As the python programmer can't (and probably doesn't want to) give parameters while importing a module, the python-uno binding uses the pyuno[rc|.ini] file located beside the pyuno shared library to bootstrap the UNO context (see uno bootstrap variable concept). The bootstrap variables UNO_SERVICES must point to a registry file where the components, given above, were registered.

PYUNOLIBDIR is a special bootstrap variable, which contains the path to the currently used pyuno shared library. Example:

# The bootstrap variable PYUNOLIBDIR will be set by the pyuno runtime library
UNO_TYPES=$PYUNOLIBDIR/types.rdb
UNO_SERVICES=$PYUNOLIBDIR/pyuno_services.rdb

If the above preconditions are fulfilled, the script can simply be started with

Sometimes it is preferable to mention the librarynames of the desired components directly within the script instead of preparing a registry (however note that the above mentioned bootstrap components always needs to be registered in a registry). This can be achieved by using the function unohelper.addComponentsToContext( toBeExtendedContext, contextRuntime, componentUrls, loaderName )

Example:

import uno
import unohelper

localContext = uno.getComponentContext()

unohelper.addComponentsToContext(
       localContext, localContext, ("streams.uno",),
       "com.sun.star.loader.SharedLibrary")

pipe = localContext.ServiceManager.createInstanceWithContext(
              "com.sun.star.io.Pipe", localContext )

pipe.writeBytes( uno.ByteSequence( "abc" ) )
ret,seq = pipe.readBytes( None, 3 )

Replacing the python runtime with your system's python installation

The replacement is a little complicated however you just need an installed python and office.

Windows

On windows, you can only use python-2.2. If you want to use python-2.3, you must recompile the pyuno module with python-2.3 (see below)

• Install OpenOffice.org
• Install python 2.2
• Use your favourite text editor (e.g. notepad) to open the file OpenOffice.org/program/pythonloader.uno.ini and modify the lines there to something like

  [Bootstrap]
  PYTHONHOME=file:///c:/python-2.3.4
  PYTHONPATH=$PYTHONHOME/lib $ORIGIN


  The path elements must be entered as absolute file urls (note that you need to escape using url syntax, for example a space is represented by %20). The PYTHONPATH must point to the root python library location and to OOo program directory. Add other libraries as you need them ( space separated).
• Rename the following files and directories in the OpenOffice.org/program directory to something else (e.g. add a .orig suffix)
  • python.bat
  • python22.dll
  • python-core-2.2.2
• Start a cmd shell and add to the PATH variable both to python home directory and OpenOffice.org/program directory
• Add to the PYTHONPATH environment variable the OpenOffice.org/program directory

Linux

On Linux, you can use both use python-2.2 or python 2.3, but when using the latter, you get a warning on stderr (informing you about the version mismatch) when starting python or the office, to avoid the warning, you need to rebuild pyuno with python-2.3 (see below), however I haven't noticed any difficulties because of the version mismatch.

• You need a python configured with the --enable-shared option. When OOo and python were not built with the same gcc compiler version, you also need to rebuild python, because the default python uses some bad switches during linking.

  To rebuild do

  LINKCC=gcc
  export LINKCC
  ./configure --enable-shared
  make
  su -c "make install"


• Switch to the OpenOffice.org directory and move away the python runtime coming with OOo.

  cd /path/to/openoffice.org/program
  mv libpython.so.2 libpython.so.2.orig
  mv python-core python-core.orig
  cp pythonloader.unorc pythonloader.unorc.orig
  ln -s /usr/local/lib/libpython2.3.so.1.0 libpython.so.2


• Add the office/program directory to the LD_LIBRARY_PATH and PYTHONPATH variable.
• Create the file pythonloader.unorc in the office/program directory.

  [Bootstrap]
  PYTHONHOME=file:///usr/local
  PYTHONPATH=$PYTHONHOME/lib/python2.3 $ORIGIN


  The path elements must be entered as absolute file urls (note that you need to use URL escape sequences for example replacing spaces with a %20). The PYTHONPATH must point to the root python library location and to OOo program directory. Add other libraries as you need them (space separated).

Testing

I did only some rudimentary tests, but I didn't notice any significant problems. Let us know, if you have some.

Note that the Bibus project uses an extended python 2.2.2 with the wxPython/wxWindows extension for the GUI.

Rebuilding pyuno

setenv PYTHONPATH /usr/local/lib/python2.3:.:/usr/local/lib/python2.3/lib-dynload

When the test runs fine, you can now replace pyuno.so, libpyuno.so and pythonloader.uno.so in the office with your rebuilt version.

Regressiontests

• Build testtools module and run

  cd testtools/source/bridgetest/pyuno && dmake runtest


• Build installation sets and install openoffice.
• Start program/python and type

  import uno


  (should work without any errors).
• Start the office and add the pyuno_hello_world.zip from the above pyuno-doc.zip by using Tools/Package Manager.
• Start Tools/Macros/Run macro/OpenOffice.org Macros/pythonSamples/TableSample/createTable

External references

Frequently Asked Questions

1. Why do I get a 'bus error' when starting the hello-world-script on Solaris ?

   There seems to be a corrupted version of the libpyuno.so in the OpenOffice.org1.1.0 installation set. The reason is not yet clear, might be either a bug in pyuno code or a build error. Please download libpyuno.so.gz to patch OOo1.1.0 version (do not apply this patch on any other version than OOo1.1.0 Solaris sparc!).

2. Why do I get a 'SystemError: pyuno runtime is not initialized, ...' when starting the script ?

   • Pyuno was not installed correctly (OO1.1RC2 and earlier, fixed with RC3). Please check

     <openoffice-install>/program $ ls -c1d py*

         pyunorc
         pythonloader.py
         pythonloader.unorc
         python
         python.sh
         python-core
         python-core-2.2.2
         pythonloader.uno.so
         pyuno.so


     Under certain circumstances, it may occur, that the following ini files are missing

     pyunorc (or pyuno.ini on windows):

     [Bootstrap] UNO_TYPES=$ORIGIN/types.rdb UNO_SERVICES=$ORIGIN/services.rdb

     pythonloader.unorc (or pythonloader.unorc on windows):

     [Bootstrap] PYTHONHOME=$ORIGIN/python-core PYTHONPATH=$ORIGIN/python-core/lib $ORIGIN/python-core/lib/lib-dynload $ORIGIN

     Simply cut and paste them into a text editor to create them.

   • There have been reported some failures with the above error message, which have not been resolved yet. You may want to follow #i17339#.

3. Why do I get a 'SystemError: _PyImport_FixupExtension: module pyuno not loaded' when starting the script ?

   This generally happens when you still start the system's python installation. OpenOffice.org ships a python installation (because python and the office must have been built with the identical compiler version). Please check this with 'which python'. Simply use OpenOffice.org's python with absolute path names, for example use /usr/local/OpenOffice.org1.1/program/python myscript.py.

4. Why do I get a "error: python-loader:'No module named pythonloader'" when running pkgchk with a python component ?

   Make sure to unset PYTHONPATH and PYTHONHOME (which you may have set, because you have another python installed on your system) environment variables before running soffice AND pkgchk. This is a workaround, We are currently thinking about a better solution.

5. Why do I get an error message 'msvcr70.dll or python22.dll not found' when starting python ?
   (or Why do I get an 'error while loading shared libraries: libstdc++.so.x' ? )

   You probably try to start python from the exe not the bat file, for example, c:\program files\OpenOffice.org1.1\program\python-runtime\bin\python.exe, but you have to use c:\program files\OpenOffice.org1.1\program\python.bat.

6. Why do I get 'PYTHONPATH=... is not an identifier' when starting python ?

   This is a bug in the python script which occurs with older bash shell versions. Simply use a text editor to change the following lines in the OOo-install/program/python.sh script

   export PYTHONPATH="$sd_prog":"$sd_prog/python-core/lib":"$sd_prog/python-core/lib/lib-dynload":"$PYTHONPATH" export PYTHONHOME="$sd_prog"/python-core

   to

   PYTHONPATH="$sd_prog":"$sd_prog/python-core/lib":"$sd_prog/python-core/lib/lib-dynload":"$PYTHONPATH" export PYTHONPATH PYTHONHOME="$sd_prog"/python-core export PYTHONHOME

   This bug is fixed with OOo 1.1.1.

7. I already have python installed on my system, why does the office ship another python ?

   Python itself is shipped with OpenOffice.org, because

   • python must have been compiled with the same C++ compiler as the office itself on all platforms that use the gcc compiler (e.g. Linux, BSD, etc.).
   • On most Unix platforms, no python shared libraries are available by default (though some distributions do so). This would have meant, that python UNO components cannot be executed within the office process.
   • Python component developers need a guaranteed minimum platform which they can rely on.
   • Recognition of a python runtime at the installation system would have been an extremely difficult and time consuming task becausemany different python installation schemes exist.
   • Packagers of OpenOffice.org will create their own packages, for example redhat or debian, without Python. The standard distribution must run on low end systems.

8. Can I use system's python installation ?

   See here.

9. Why does my UNO component crash OpenOffice.org, while the sample UNO component runs fine?

   There is a known bug in the office, see #i13377#, which was not fixed for OpenOffice.org1.1. The office in general crashes, when a python script leads to an unhandled exception (for example an attribute error).

   You may try to workaround this bug by adding a try: except: level in your trigger() implementation, which dumps an error message to stdout/stderr, but sadly this will not help in all cases (for example compilation failure for some reason, please follow the issue for further information).

   Of course, there may be other reasons for a crash, you will only know, when you try to retrieve a native callstack (for example by using gdb).

10. Why doesn't Python's xml parser (expat) or the zip module work for me?

    These libraries don't yet get built for OOo1.1. This will change for OOo2.0. Alternatively you may use OpenOffice.org's xml parser service (see service com.sun.star.xml.sax.Parser) or the zip content provider (see http://ucb.openoffice.org).

11. Why doesn't socket and sre module work in OOo1.1. python distribution on windows?

    This is a known bug on windows in the OOo1.1 build. This should be fixed for OOo1.1.1 (see issue 21281 ). It should work for the other platforms. You can workaround this by downloading the official windows python distribution (see http://www.python.org) and replacing the appropriate .pyd files in the OOo's python installation.

12. The samples are running fine, but how do I get more information about the API ?

    The semantics of the OpenOffice.org API is a very complex topic, which can't be discussed in this python document. Try to gather information from other resources, especially from the developer manual (see below).

13. Most examples in the devguide are in Java. How do I translate them to python code ?

    Most sample code you find there is written in Java. It is easy to translate Java code to python,when you know the following differences:

    In python you don't need queryInterface. E.g. Java code like

    oInterface = (XInterface) oMSF.createInstance( "com.sun.star.frame.Desktop" ); oCLoader = ( XComponentLoader ) UnoRuntime.queryInterface( XComponentLoader.class, oInterface ); PropertyValue [] szEmptyArgs = new PropertyValue [0]; aDoc = oCLoader.loadComponentFromURL( "private:factory/swriter" , "_blank", 0, szEmptyArgs );

    becomes in python simply

    oCLoader = oMSF.createInstance( "com.sun.star.frame.Desktop" ) aDoc = oCLoader.loadComponentFromURL( "private:factory/swriter", "_blank", 0, () )

    You don't need this intermediate oInterface variable anymore. So the python code simplifies the example a lot, with a little training, you shouldn't have too many problems to translating Java to python code.

14. Why can't I call the print method?

    In python, 'print' is a statement. This basicly means there is no way to get a variable, method or anything else with this name. For example the below code does not work:

         doc = desktop.loadComponentFromURL(infileurl, "_blank", 0, ())
         doc.storeAsURL(outfileurl, ())
         doc.print(())


    You can workaround the problem by using the uno.invoke() function like below :

         uno.invoke(doc, "print", ((), ))


15. Why can't I do a replace on the 'NumberingRules' object ?

    There are some places, where the loss in type safety leads to difficulties, as this issue shows http://www.openoffice.org/issues/show_bug.cgi?id=12504. The problem here is, that the C++ implementation within the office expects a sequence< PropertyValue >, while the PyUNO runtime converts it to a sequence< any>, where each any contains a PropertyValue. In my eyes, this is a bug within the C++ code. However here is a workaround for pyuno that the python scripter can use. See the sample below:

    import uno import unohelper localContext = uno.getComponentContext() resolver = localContext.ServiceManager.createInstanceWithContext( "com.sun.star.bridge.UnoUrlResolver", localContext) ctx = resolver.resolve( "uno:socket,host=localhost,port=2002;urp;StarOffice.ComponentContext") smgr= ctx.ServiceManager desktop = smgr.createInstanceWithContext("com.sun.star.frame.Desktop",ctx) doc = desktop.loadComponentFromURL("private:factory/swriter", "_blank", 0, ()) style = doc.createInstance("com.sun.star.style.NumberingStyle") family = doc.getStyleFamilies().getByName('NumberingStyles') family.insertByName('List test', style) rule = style.getPropertyValue('NumberingRules') level = rule.getByIndex(0) # the normal call would have been: # rule.replaceByIndex( 0, level ) # but this will end up in a exception # magic to pass the exact type to the callee uno.invoke( rule , "replaceByIndex", (0, uno.Any("[]com.sun.star.beans.PropertyValue",level)) )

    This is the only place, where the uno.Any is used. Using the uno.Any in normal calls will lead to RuntimeExceptions. A python uno object implementation will never receive an instance of uno.Any() as a incoming parameter, instead always the value within the is passed.

    This solution looks really ugly, but it allows you to continue, where you otherwise could only give up or use to another implementation language.

16. How can I activate encoding iso8859-1 for OpenOffice.org's python installation ?

    Put a file called sitecustomize.py somewhere in your PYTHONPATH containing:

    import sys
    sys.setdefaultencoding('iso8859-1')


    (or any other encoding you wish). However, note that this is generally not such a good idea. It would be much cleaner to do the necessary conversions explicitly in the code, for example using Unicode(x, 'iso8859-1').

Known PyUNO extensions for OpenOffice.org

Packages listed here can be taken as a demo of what is possible with pyuno. Let me know, if you are aware of other extensions using pyuno.

PyUNO needs YOU !

PyUNO is currently (and will be in future) maintained by myself in my spare time.

My main aim for pyuno is to provide a good integration of OpenOffice.org's component model into python. Some guys on dev@udk.openoffice.org demand to have a more feature rich python runtime in OpenOffice.org and an integration with the system's python installation. While this is an understandable demand, it is not one of my favourite topics to work on and it involves quite a lot of work. As I also spend time on the creation of a postgresql driver for OpenOffice.org, there is simply no time left for this task.

So I am looking for other volunteers such as you to fill this gap. In case you are interested, let me know via the dev@udk.openoffice.org mailing list or drop me a mail privately.

I currently see the following main tasks

Authors

The UNO python bridge was initially created by Ralph Thomas and is now maintained by Joerg Budischewski. Christian Zagrodnick sent in some very useful patches. Many unmentioned porters made it possible to have pyuno on all platforms supported by OOo. Last updated $Date: 2008/10/16 22:02:35 $

Please use the dev@udk.openoffice.org mailing list for further questions.

License
